Moretop vacuum brazed diamond blade 230mm multipurpose cutting
- Model
- 10124005
Item specifics
- Brand
- profi
- Diameter
- 230mm
- Diamond Grit
- 35#
- Bore
- 22.23mm
- Segment Thickness
- 2.8mm
- Plate Thickness
- 1.8mm
- Max.RPM
- 6600
- For machine
- DeWalt,Makita,Bosch,etc.
Review
Description
It is the most popular saw blade we offer
MORETOP Vacuum Brazed Diamond Blade is suitable for cutting on wood,metal,stone, marble and other materials.
It's produced by high-temperature vacuum brazing technology for firmly attached diamond particles, fast cutting and long service life.
It's not easy to deform at high temperature with good stability painted by UV processing technology and packed in customized package.
for cutting Everything
FEATURES:
PROFI Universal Diamond Blade uses a process of vacuum brazing to attach large pieces of diamond grit to be held constantly
in contact with different materials being cut in efficient way.
APPLICATIONS:
Concrete, Reinforced Concrete, Paving, Indian Sandstone, Quarry Stabs, Granite, Plastic, Ducting, Glass, Rubber and Fibreglass.
BENEFITS OVER CONVENTIONAL ABRASIVE WHEELS
Cost Efficiency: long tool life and less down time
Environmental and Operator Friendly: reduced sparks and no odour
Safety: wheel breakage eliminated
Wheel Wear: reduction in tool size or sharpe
Saving Time: one blade for cutting everything.
Description | Item No. | Dia.(mm) | Diamond Grit | Bore(mm) | Plate Thickness | Segment Thickness | RPM |
Cuting for everything | 10124001 | 105 | 35# | 22.23 | 1.2 | 2.2 | 14500 |
10124002 | 115 | 35# | 22.23 | 1.2 | 2.2 | 13300 | |
10124003 | 125 | 35# | 22.23 | 1.2 | 2.2 | 12200 | |
10124004 | 180 | 35# | 22.23 | 1.8 | 2.8 | 8600 | |
10124005 | 230 | 35# |
22.23
|
1.8
|
2.8
|
6600
|
|
10124006 | 300 | 35# |
25.4
|
2.2
|
3.2
|
6300
|
